Walker 7070 Log Only is a Speed Log System providing electromagnetic log data from a single processor.
This compact, cost effective system takes advantage of “state of the art” electronics to process the log sensor input, outputting digital data on a single NMEA 0183 data bus to DIN 144 data displays.
Walker 7070 electromagnetic log is designed for vessels above 500GRT, offering both forward and astern speed, with ranges from -0 to 80 knots full scale. It is suitable for vessels varying from patrol boats and ferries to liners and bulk carriers.
Warning: Trying to access array offset on false in /var/www/html/marcom.itvally.com/wp-content/themes/flatsome/woocommerce/single-product/product-image.php on line 94
Warning: Trying to access array offset on false in /var/www/html/marcom.itvally.com/wp-content/themes/flatsome/woocommerce/single-product/product-image.php on line 95
Warning: Trying to access array offset on false in /var/www/html/marcom.itvally.com/wp-content/themes/flatsome/woocommerce/single-product/product-image.php on line 96
Warning: Trying to access array offset on false in /var/www/html/marcom.itvally.com/wp-content/themes/flatsome/woocommerce/single-product/product-image.php on line 97
FEATURES
- Full sensor compatibility with Walker log systems.
- Digital display to DIN 144 for log speed and distance travelled.
- 4 point speed log calibration.
- NMEA 0183 interface to systems.
- Ease of installation, use and service.
Specifications
- Mechanical Dimensions :
Speed log sensor and hull fittings with sea valve : 387 (W) x 165 (D) x 578 (H)
Speed log sensor and hull fittings without sea valve : Ø 152 x 178(H)
Electronic Unit :
411(H) x 238(W) x 152(D) DIN 144 Displays : 144(H) x 144(W) x 105(D)
Power Supply Unit : 240(H) x 200(W) x 128(D)
- Electrical requirements :
Power supply : 110v AC or 220v AC (with PSU) or 24v DC
Power requirement : 30 VA(AC) or 20w (DC)
- Interfaces :
Outputs :
2 x NMEA 0183 log speed log distance
2 x 200 ppNM isolated relay contacts of distance travelled Sensor Input for log
