As an important device of GMDSS, MF/HF WT-6000 adopts newest advanced software radio technology and RF digital technology; providing strong performance of reception, emission and operation. It is fully compliant with IMO A.806(19), IEC 61097-03, IEC 61097-09, IEC 60945, ITU-R M.493-13 and other relevant international standards. Meanwhile it also provides abundant external interfaces, supporting function of remote control, external modems and other devices. MF/HF WT-6000 and its derivative products are used in variety ships. According to international maritime rules, the ships working in area of A2 to A4 must install this device. Besides, its derivative products can be used by land users as required. And it is certified by: COSPAS, CCS and ZY, meeting with standard of IMO/IEC
Features
- Providing SSB, AM, DSC operation mode
- One-click answer and forwarding of distress alarm and help signal
- Squelch function</li>
- Fully compliant with IMO DSC requirement
- Six distress channels simultaneously on duty, six routine scan channel on duty, one SSB fixed frequency channel on duty.
- GPS built-in, supporting internal and external switch of GPS, supporting BD and GLONASS navigation system(Optional)
- Supporting desktop installation and embedded installation
- Supporting software remotely upgrade
Specifications
Frequency Range: 1.605MHz ~ 27.5MHz (TX) , 0.5MHz ~ 30MHz (RX)
Frequency Stability: 10Hz
Modulation Type: SSB, DSC AM
Operating Temperature Range: -1 5°C ~ 55°C
Power Requirement: 13.BVDC +30%/-10%
Power Consumption: RX: <1.0A; TX: <20A (Max)
Protection Function: Overvoltage, Under-voltage, Over-current, Reverse, High VSWR protection
External Interface: RS422, USB2.0
