G1 GNSS SATELLITE COMPASS

Features

• Supports both GPS and GLONASS satellites for complete redundancy
•  Heading accuracy < 0.5° rms
• Position accuracy < 1.0m 95% confidence (DGPS)
• An integrated 9 Axis Inertial Measurement Core (IMC technology) provides enhanced roll, tilt and heading stability even during momentary loss of satellite signals
• G3 color display system (optional)
•  Engineered enhancements to exceed sealed IP67 rating
• Extended 2 year warranty
• NMEA 0183 and NMEA 2000® interface
• Heave, Pitch, Roll and Rate of Turn as standard output
• Heading updates 1 to 20 Hz
• BAUD Rate selectable: 4800, 9600, 19200, 38400,115200
• Fully compatible with on board NMEA 0183 and NMEA 2000® RADAR, ECDIS, AIS, Cameras, SONAR, PC and Autopilots
• Compact integrated surface mounting and pole mount
• Pre-programmed default settings for Heading, Rate of Turn, Course over Ground, Lat/Long position, Time & Date
• 15 meter serial cable standard (30 meter optional)
• 6 meter NMEA 2000® Cable (Optional)
• CE certified for EMI and RFI immunity
• Worldwide service

Specifications

• Receiver Type : L1, C/A code, with carrier phase smoothing
• Channels : Two x 32 parallel tracking GPS, GLONASS, SBAS
• Update Rate : Standard 10 Hz, Selectable up to 20 Hz
• Horizontal Accuracy : < 0.5m 95% confidence (DGPS)*    < 2.5m 95% confidence (autonomous, no SA)**
• Heading Accuracy : < 0.50° rms
• Pitch / Roll Accuracy : < 1° rms
• Heave Accuracy : < 30 cm rms
• Rate of Turn : 45º / sec max
• Start-up Time : < 60 sec typical
• Input Voltage : 10 to 36 VDC
• Current Consumption : ~ 240 mA @ 12 VDC
• Power Consumption : ~ 2.8 W nominal
