ComNav Autopilots offer precise and steady vessel steering with easy settings for seamless performance at various speeds. Professional performance is further achieved by independent rudder response setting capability for fast and slow vessel speeds.Stable course holding resulting in fuel savings .
Features
-
Clip mounted allowing both fixed and hand held operation
-
Suitable for small to mid-sized vessels
-
Capable of operating on most standard types of steering systems
-
Waterproof Control Head
-
Automatic yaw, sea state and trim
-
Output for optional analog rudder angle indicator, up to 4 stations
-
Easy course changes, from one degree to major changes, with the push of a button
-
“Nav” mode accepts NMEA 0183 information
-
One NMEA 0183 Heading Output (HDM & HDG)
-
Reliable in any sea and weather condition
-
Easy to install and fully compatible with your onboard instruments
-
Fourteen selectable steering parameters for both Fast and Slow Modes
-
Extended 3 year warranty
-
Meets CE requirments
Specifications
-
Operating Voltage : 10-40 VDC
-
Power Consumption : Average 3 amps, 20 amps Peak
-
Solenoid Output : 20 amps max.
-
DC Reversing Pump : 20 amps max.
-
Clutch Output : 3 amps max.
-
Navigational Interface : NMEA 0183
-
Heading Reference : Fluxgate / Magnetic Compass
-
Course Resolution : 1º
-
Course Detection : 0.25º
